Interface is the world’s trusted leader in technology, design, and manufacturing of force measurement solutions. We guarantee the highest quality performance of load cells, torque transducers, multi-axis sensors, wireless telemetry, instrumentation, and calibration. We empower engineers around the world to measure force and performance at the highest degree.
Interface’s core differentiator in the test and measurement industry is precision. We are known for providing high-accuracy, innovative solutions, engineering excellence and quality products that clients trust. Our organization is galvanized through our foundational 4-pillars: quality, service, accuracy, and innovation.
Interface is the world’s largest producer of low profile load cells.
Interface load cells will outperform competitors load cells, guaranteed.
Interface is the “standard” load cell in the industry. Our LowProfile® load cells are used throughout the world and have been recognized as the leader in accuracy and dependability since 1968 by leading companies in the automotive, aerospace, energy and medical industries as well as most testing labs.
Our Gold Standard Calibration System is the industry ‘gold standard’ for test and measurement. Interface is the only major load cell company offering a comprehensive system for customers to calibrate their own load cells. Many calibration labs and other manufacturers calibrate their load cells with Interface Gold Standard Calibration Systems.
Gold Standard® Calibration System
1600 Gold Standard® Calibration LowProfile® Load Cell
1601 Gold Standard® Calibration Compression-only LowProfile® Load Cell
1606 Gold Standard® Low Capacity Calibration Load Cell
Every LowProfile™ load cell we make is individually calibrated and tested through a series of performance tests, with no sampling, before it is shipped.
We manufacture our own self-temperature compensated strain gages from our exclusive proprietary alloy. Our strain gage bridges utilize an effective temperature compensation circuit design without adding modulus resistors as do most competitors. Zero temperature sensitivity is tested at both cold and hot temperatures for every sensor.
Every load cell batch is creep tested to the tightest specification in the industry.
Larger Interface force sensors use eight strain gages to assure delivery of the highest accuracy in the industry, while other load cell manufacturers use four or less.
Every Interface LowProfile™ load cell is moment compensated to minimize sensitivity to extraneous loads.
Interface provides higher outputs for better signal-to-noise ratio. Our low profile load cells provide 4mV/V output above 2.5K lbf capacity (versus 2 or 3mV/V).
All Interface calibrations are NIST traceable. And our lab has A2LA accreditation for both load cell and torque sensor calibration.
Our vertical integration means shorter lead times, better quality control and lower costs. Many manufacturers farm out their CNC work. Interface machining is programmed directly from the same 3D software used to design the load cell. Our strain gages are made and assembled in the same buildings as our final sensor testing is performed in-house.
We modify and customize force measurement solutions, delivering the broadest variety of available options in the industry. We help to design, create and build precisely customers require, quickly and cost-effectively.
Here at Interface we manufacture more than 60 different types of load cells and interface Mini’s™. We have capacities ranging from 1 lbf / 500 gf to 2 million lbf / 9,000 kN. Our facility produces them in several shapes and sizes. Models similar to pancake load cell and donut load cell including our LowProfile® load cell and thru-hole load cell.
Additionally, our canister, rod end, downhole, column, coil tubing, load buttons, and load washers all use our proprietary alloy strain gages. This helps us produce the most accurate and reliable data possible. Therefore, with the wide variety of load cell specs we have in stock, most customers are able to use an off-the-shelf application. However, our engineers can also work with you to design a custom load cell to fit your exact needs. Contact us so that we can help you find a solution that fits your needs.
Interface produces nearly 50 types of reaction torque transducers and rotary torque transducers. All our torque transducers are precision-machined and use our proprietary torque sensors for the most accurate data possible. A torque sensor, is a transducer that converts a torsional mechanical input into an electrical output signal. A reaction torque sensor measures static torque, and rotary measures dynamic torque. Rotary torque transducers are used in applications where the torque transducer must rotate when attached to a spinning shaft. A rotary torque transducer provides a method of getting the signal off of the rotating element without an attached cable. We can help you find mounts from pedestals to shafts to flanges, and drives vary from hex to square to pulley, with more styles in between.
Multi-Axis Sensors are designed to measure a multiple of forces and moments simultaneously with a single load cell sensor. These sensors provide multiple bridges that precisely measure the applied force from one direction with little or no cross-talk from the force or moment. Our 3-axis, 6-axis, and axial torsion load cells provide the ultimate in force and torque measurement. We can measure forces simultaneously in three mutually perpendicular axes, with the 6-axis load cells also measuring torque around those axes.
Interface’s wide range of load pins are designed for the measurement of tensile and compressive forces across a wide variety of applications, including crane/lifting, industrial, marine, offshore, and civil engineering. Machined from high tensile stainless steel, our load pins are suitable for use in exposed situations including prolonged immersion in seawater. The tension link series are designed for lifting and weighing applications in harsh environments and manufactured from high tensile aluminum and stainless steel. The load shackle pins are manufactured from high tensile carbon steel and while the basic shackle uses the renowned Crosby G2130, G2140, and G2150 series (depending on the load rating).
Interface’s wide range of load pins are designed for the measurement of tensile and compressive forces across a wide variety of applications, including crane/lifting, industrial, marine, offshore, and civil engineering. Machined from high tensile stainless steel, our load pins are suitable for use in exposed situations including prolonged immersion in seawater. The tension link series are designed for lifting and weighing applications in harsh environments and manufactured from high tensile aluminum and stainless steel. The load shackle pins are manufactured from high tensile carbon steel and while the basic shackle uses the renowned Crosby G2130, G2140, and G2150 series (depending on the load rating).
Interface’s wide range of load pins are designed for the measurement of tensile and compressive forces across a wide variety of applications, including crane/lifting, industrial, marine, offshore, and civil engineering. Machined from high tensile stainless steel, our load pins are suitable for use in exposed situations including prolonged immersion in seawater. The tension link series are designed for lifting and weighing applications in harsh environments and manufactured from high tensile aluminum and stainless steel. The load shackle pins are manufactured from high tensile carbon steel and while the basic shackle uses the renowned Crosby G2130, G2140, and G2150 series (depending on the load rating).
Interface Load Cell Calibration Systems are available in design configurations for a wide range of rigid and portable systems. We offer strain gage load cell calibration systems for nearly any force measurement application including custom designs. Our GS-SYS Gold Standard® Calibration System consists of a four-post rigid load frame, proprietary load feedback loop, signal conditioning hardware, and fully-automated calibration software for the highest accuracy and lowest uncertainty available. Portable versions of the GS-SYS system are also available for calibrating load cells and test equipment.
Interface provides instrumentation such as signal conditioners, output modules, high speed data loggers, portable load cell indicators, weight indicators, and junction box. We also offer full data acquisition and wireless telemetry systems for Load Cell and Torque Transducers. Our Multi-Channel Bridge Amplifier has a 4-Channel Capability, while the INF-USB3 Universal Serial has a Sensor to USB Output Converter.
Use the NEW Interface Instrumentation Selection Guide to assist you in choosing the instrument best suited for your application.
Interface provides a wide range of digital instruments that take load cell or strain bridge input and provide data output in a variety of protocol and bus formats, including a wide range of industry standards.
Use the NEW Interface Instrumentation Selection Guide to assist you in choosing the instrument best suited for your application.
Wireless Telemetry System (WTS), Sensor Transmitters, Receivers, and Displays. High accuracy, high quality measurement is interfaced with simple yet powerful configuration and monitoring software. The WTS gives sensor manufacturers and integrators the complete flexibility to build their own sensor modules around it. The system easily replaces wired systems, reducing installation and maintenance costs.
Interface’s load button cells are designed for customers who require the measurement of forces in a very confined space. They are designed to provide the most accuracy in as little space as possible. The smaller LBM or LBS can fulfill the need for force measurements at a very respectable precision level that is enough for most applications. Diameters range from 1 inch to 3 inches, with heights from 0.39 inch to 1.5 inches. The shaped load button has a spherical radius to help confine misaligned loads to the primary axis of the cell.
Interface offers eight different models of load washers of varying sizes and force measuring ranges, all the way from 11.2 to 1124K lbf. The Interface Load Cell Load Washers can be easily designed into products to continuously measure and monitor compression forces. The variety of styles and capacities, all using the thru-hole feature, give product engineers and designers multiple choices for what best fits their application and use case.
Interface offers two types of load frames. The Gold Standard® Calibration System using the Interface Gold Standard® Load Cell ensures a metrology system of the highest accuracy and lowest uncertainty available. The second is the Force Verification Frame which is a portable high force capacity frame and accessories designed to apply tension and compression forces to load cells with high resolution and accuracy. This system features a reaction frame, manual actuator, thread/adapter accessories, and optional force sensor(s) and instrumentation. The hardware can be used to verify operation of a device under test or calibrate relative to a second reference load cell.
We provide shielded cable and mating connectors to calibration adapters and resistors. Our top and bottom plates distribute load over the support structure foundation and provide a prepared surface for the load cell. Precisely machined clevises, jam nuts, thread adapters, mating connectors, mounting plates, and rod end bearings provide rigid connections and reduce alignment error. Load cell and torque transducer accessories are available in many design configurations and will help you complete your project design with the highest performance and the least amount of trouble possible.
Interface’s specially designed low profile load cells with loop-powered intrinsically safe amplified output for use in oil field and other hazardous locations. These load cells are derived from other proven Interface models by adding high resistance strain gages for low-current loop power and shielded internal amplifier for extra low emissions and minimal EMI susceptibility. Interface’s S-type load cell provides a suitable force measurement sensor for applications in coal mining and transfer and other heavy industries where explosive dusts and environment conditions are potentially explosion-hazard rated.
Why Choose Interface For Calibration And Repair Services?
Interface provides calibration and repair services on load cells and other force measurement devices from nearly any manufacturer. We perform more than 100,000 calibrations annually on devices shipped to Interface for recalibration, as part of the post-repair process, or on devices newly manufactured by Interface. Repairs include a complete evaluation of the device prior to repair and calibration upon completion.
Interface Custom Solutions empowers you to utilize our expert engineering, design and manufacturing teams to build custom force and torque applications that meet your exact needs with precision. It’s what we have been doing for 50 years.
Our robust capabilities include customization of complete solutions, designed with FEA (finite element analysis), as well as proprietary Interface strain gages. All is done in our state-of-the-art machine shop headquartered in the US, supported by our world-class assembly and calibration. Most important, our custom solutions follow all industry leading quality standards that deliver precision-based accuracy measurement solutions.
Interface’s experienced team are renowned specialists in force or torque measurement manufacturing and technology. Our depth of knowledge and wide range of capabilities create custom solutions of all types, whether special transducers made to your exact specifications or complete customized sensor, instrumentation, and software systems. We collaborate with you to ensure your specifications are designed to meet your exact use requirements.
American Association for Laboratory Accreditation (A2LA) is among the largest accreditation bodies in the world and the only independent, 501(c)3, non-profit, internationally recognized accreditation body in the United States that offers a full range of comprehensive conformity assessment accreditation services.
Established in 1978 as a public service membership society, A2LA is dedicated to the formal recognition of competent testing and calibration laboratories (including medical laboratories), biobanking facilities, inspection bodies, product certification bodies, proficiency testing providers, and reference material producers. A2LA has over 4,000 actively accredited certificates representing all 50 US states and more than 50 countries. For a current listing of A2LA’s accredited organizations, please search our directory.
A2LA offers three primary service lines to support recognition of competence in conformity assessment industries.
ISO/IEC 17025 enables laboratories to demonstrate that they operate competently and generate valid results, thereby promoting confidence in their work both nationally and around the world.
It also helps facilitate cooperation between laboratories and other bodies by generating wider acceptance of results between countries. Test reports and certificates can be accepted from one country to another without the need for further testing, which, in turn, improves international trade.
Accreditation to ANSI/NCSL Z540-1 is available for both calibration and testing laboratories to ensure that laboratories control their own measuring and test equipment to the highest national standards.
1.1 The purpose of these practices is to specify procedures for the calibration of force-measuring instruments. Procedures are included for the following types of instruments:
1.1.1 Elastic force-measuring instruments, and
1.1.2 Force-multiplying systems, such as balances and small platform scales.
NOTE 1: Verification by deadweight loading is also an acceptable method of verifying the force indication of a testing machine. Tolerances for weights for this purpose are given in Practices E4; methods for calibration of the weights are given in NIST Technical Note 577(1)2, Methods of Calibrating Weights for Piston Gages.
1.2 The values stated in SI units are to be regarded as the standard. Other metric and inch-pound values are regarded as equivalent when required.
1.3 These practices are intended for the calibration of static force measuring instruments. It is not applicable for dynamic or high speed force calibrations, nor can the results of calibrations performed in accordance with these practices be assumed valid for dynamic or high speed force measurements.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
4.1 Testing machines that apply and indicate force are in general use in many industries. Practices E4 has been written to provide a practice for the force verification of these machines. A necessary element in Practices E4 is the use of force-measuring instruments whose force characteristics are known to be traceable to the SI. Practices E74 describes how these force-measuring instruments are to be calibrated. The procedures are useful to users of testing machines, manufacturers and providers of force-measuring instruments, calibration laboratories that provide the calibration of the instruments and the documents of traceability, service organizations that use the force-measuring instruments to verify testing machines, and testing laboratories performing general structural test measurements.
Standard Practices for Calibration and Verification for Force-Measuring Instruments
NIST Certified Gold and Platinum Standard Reference Load Cells Testing and Calibration
National Institute of Standards and Technology (NIST) U.S. Depart of Commerce
Instruments and Related Products Manufacturing for Measuring, Displaying, and Controlling Industrial Process Variables
Other Measuring and Controlling Device Manufacturing
Analytical Laboratory Instrument Manufacturing
Instrument Manufacturing for Measuring and Testing Electricity and Electrical Signals
Pressure, Temperature and Humidity Measuring Instruments
Equipment and Materials Testing Services/Maintenance and Repair Shop Equipment
Equipment and Materials Testing Services/Engines, Turbines and Components
Equipment and Materials Testing Services/Special Industry Machinery
Equipment and Materials Testing Services/Instruments and Laboratory Equipment
Misc. Testing & Inspection Services
Other Quality Control Services/Engines, Turbines and Components
Other Quality Control Services/Measuring Tools
Other Quality Control Services/Instruments and Laboratory Equipment
Electrical and Electronic Measuring Instruments
Laboratory Equipment and Supplies
Interface clients are the who’s who in aerospace, automotive and vehicle, medical devices, energy, test and measurement, and industrial manufacturing. Interface, Inc., was founded in 1968 and is a US-based, women-owned technology manufacturing company headquartered in Arizona.
