Data AQ Pack Guide
Interface Data AQ Pack Systems
Products in this guide are complete data acquisition products that are offered by Interface and ensure top performance with any Interface transducer.
BlueDAQ Instrument Family Data AQ Pack
BlueDAQ Instrument Family Data AQ Pack
Single, Dual, 3-Axis and 6-Axis Force Sensor
Connecting your transducers to the BlueDAQ Family Data AQ Pack will provide you with convenient way to view the test results for your single axis, dual axis, 3-axis and 6-axis transducers. The Data AQ Pack will provide a means to setup, log, and graph and display data from your application. All Interface single, dual, 3-axis and 6-axis force sensor can be used.
Transducers
- LowProfile® Series Load Cells – 25 lbf to 2,000K lbf (111 N to 8,896 kN)
- 3-Axis Series Force Load Cells – Force: 0.45 lbf to 112K lbf (Force: 2 N to 500 kN)
- 3AR Series Round 3-Axis Load Cells – Force: 2.2K lbf to 112K lbf (Force: 10 kN to 500 kN)
- 6-Axis Series Force and Torque Load Cells – Force: 11.2 lbf to 180K lbf Torque: 8.85 lbf-in to 354K lbf-in (Force: 50 N to 800K N Torque: 1 Nm to 40K Nm)
- 6ADF Series 6-Axis DIN Flange-Type Load Cells – Force: 4.5 lbf to 269 lbf Torque: 8.85 lbf-in to 531 lbf-in (Force: 20 N to 1.2 kN Torque: 1 Nm to 60 Nm)
Instrumentation
- BX8-AS BlueDAQ Series 8-Channel Data Acquisition System With Industrial Enclosure
- BX8-HD15 BlueDAQ Series 8-Channel Data Acquisition System For Discreet Sensors With Lab Enclosure
- BX8-HD44 BlueDAQ Series 8-Channel Data Acquisition System For Multi-Axis Sensors With Lab Enclosure
- BSC1 Single Channel PC Interface Module And Bridge Amplifier
- BSC2 Dual Channel PC Interface Module
- 9330 Battery Powered High Speed Data Logging Indicator
Display Options
- X15 Pipo – Mini 11.6” FHD Screen Tablet PC with Windows 10 OS
- X4 Pipo – IP67 Rugged Waterproof 10.1” Screen Tablet with Windows 10 OS
Software
- Interface BlueDAQ Software – Scale Input/Output, Force & Moment Value Calculation, Graphing, Logging, and Display
- Interface BlueDAQ-PRO Software – Scale Input/Output, Force and Moment Value Calculation, Graphing, Logging, Display, MathScripting, and Integration of a GPE receiver and reading of GPS coordinates
Accessories
- Freestanding Pipo Stand – Freestanding Mount Height Adjustment, Swivel, Tilt, and Rotation Options For Use with X15 Pipo
WTS Wireless Data AQ Pack
WTS Wireless Data AQ Pack
On-Cable or Intergrated Wireless Acquisition Module
Connecting your transducers to the WTS Wireless Data AQ Pack will provide you with convenient wireless communication with speeds up to 200 samples per second. The Data AQ Pack will provide a means to setup, log, graph and display data and display mapping of your application. All Interface force sensor can be used.
Transducers
- WTS LowProfile® Series Load Cells – 25 lbf to 2,000K lbf (111 N to 8,896 kN)
Instrumentation
- WTS-AM-1E Wireless Strain Bridge Transmitter Module
- WTS-BS-3E Wireless Base Station With USB Interface
Display Options
- X15 Pipo – Mini 11.6” FHD Screen Tablet PC with Windows 10 OS
- X4 Pipo – IP67 Rugged Waterproof 10.1” Screen Tablet with Windows 10 OS
Software
- Interface WTS ToolKit – Setup and Scaling, Logging, and Graphing Software
- Interface Log 100 Software – Display, Logging, Graphing, and Mapping Software
Accessories
- Freestanding Pipo Stand – Freestanding Mount Height Adjustment, Swivel, Tilt, and Rotation Options For Use with X15 Pipo
T-USB-VS Rotary Torque Transducer Data AQ Pack
T-USB-VS Rotary Torque Transducer Data AQ Pack
USB Output Option Rotary Torque Transducers
Connecting your transducers to the T-USB Rotary Torque Transducer Data AQ Pack will provide you with convenient way to view the test results for your torque transducers that have internal USB functionality. The Data AQ Pack will provide a means to setup, log, and graph and display data from your application.
Transducers
- T12 Square Drive Style Rotary Torque Transducer with USB Option 0.88 lbf-in to 44K lbf-in 0.1 Nm to 5K Nm
- T15 Hex Drive Style Rotary Torque Transducer with USB Option 1.77 lbf-in to 177K lbf-in 0.2 Nm to 20 Nm
- T25 High Speed Shaft Style Rotary Torque Transducer with USB Option 0.885 lbf-in to 44.3K lbf-in 0.1 Nm to 5K Nm
Display Options
- X15 Pipo – Mini 11.6” FHD Screen Tablet PC with Windows 10 OS
- X4 Pipo – IP67 Rugged Waterproof 10.1” Screen Tablet with Windows 10 OS
Software
- Interface T-USB-VS Software – Adjustment, Control, Read-Out, Display, and Storing of Measured Values
Accessories
- USB Cable with USB Type A to USB Type B, Mini USB 2.0 IP68 Rated
- Freestanding Pipo Stand – Freestanding Mount Height Adjustment, Swivel, Tilt, and Rotation Options For Use with X15 Pipo
DIG-USB PC Interface Module Data AQ Pack
DIG-USB PC Interface Module Data AQ Pack
Force and Torque Sensors
Connecting your transducers to the DIG-USB Data AQ Pack will provide you with convenient way to view the test results for your load cell or torque transducer. The Data AQ Pack will provide a means to setup, log, and graph and display data from your application. All Interface load cell or torque transducer can be used.
Transducers
- LowProfile® Series Load Cells – 25 lbf to 2,000K lbf (111 N to 8,896 kN)
- MRT Series Miniature Flange Style Reaction Torque Transducers – 1.77 lbf-in to 443 lbf-in (0.2 Nm to 50 Nm)
- TS Series Reaction Torque Transducers – 0.04 lbf-in to 177K lbf-in (0.005 Nm to 20K Nm)
Instrumentation
- DIG-USB USB Output Module
- DIG-USB-F Fast USB Output Module
Display Options
- X15 Pipo – Mini 11.6” FHD Screen Tablet PC with Windows 10 OS
- X4 Pipo – IP67 Rugged Waterproof 10.1” Screen Tablet with Windows 10 OS
Software
- Interface DIG-USB ToolKit – Configuration, Calibration, Data Recording and Review, and Parameter Management
- Interface DIG-USB-F ToolKit – Configuration, Calibration, Data Recording and Review, and Parameter Management
Accessories
- Freestanding Pipo Stand – Freestanding Mount Height Adjustment, Swivel, Tilt, and Rotation Options For Use with X15 Pipo
INF-USB-VS3 PC Interface Module Data AQ Pack
INF-USB-VS3 PC Interface Module Data AQ Pack
mV/V Force and Torque Sensors
Connecting your transducers to the INF-ISB-VS3 Data AQ Pack will provide you with convenient way to view the test results for your load cell or torque transducer. The Data AQ Pack will provide a means to setup, log, and graph and display data from your application. All Interface mV/V load cell or torque transducer can be used.
Transducers
- T Series Rotary Torque Transducers – 0.04 lbf-in to 177K lbf-in (0.005 Nm to 20K Nm)
- SSM or SSM2 Sealed S-Type Load Cells – 25 lbf to 10K lbf (100 N to 50 kN)
Instrumentation
- INF-USB3 Universal Serial Bus Single Channel PC Interface Module
- SI-USB4 4-Channel USB Interface Module
Display Options
- X15 Pipo – Mini 11.6” FHD Screen Tablet PC with Windows 10 OS
- X4 Pipo – IP67 Rugged Waterproof 10.1” Screen Tablet with Windows 10 OS
Software
- Interface INF-USB-VS3 Software – Adjustment, Control, Read-Out, Display, and Storing of Measured Values
Accessories
- Freestanding Pipo Stand – Freestanding Mount Height Adjustment, Swivel, Tilt, and Rotation Options For Use with X15 Pipo
9325 Portable Display Data AQ Pack
9325 Portable Display Data AQ Pack
Force and Torque Sensors
Connecting your transducers to the 9325 Data AQ Pack will provide you with convenient way to view the test results for your load cell or torque transducer. The Data AQ Pack will provide a means to setup, log, and graph and display data from your application. All Interface load cell or torque transducer can be used.
Transducers
- LowProfile® Series Load Cells – 25 lbf to 2,000K lbf (111 N to 8,896 kN)
Instrumentation
- 9325 Portable Sensor Display
Display Options
- X15 Pipo – Mini 11.6” FHD Screen Tablet PC with Windows 10 OS
- X4 Pipo – IP67 Rugged Waterproof 10.1” Screen Tablet with Windows 10 OS
Software
- Interface 9325 ToolKit – Setup and Scaling, Logging, and Graphing Software
Accessories
- Freestanding Pipo Stand – Freestanding Mount Height Adjustment, Swivel, Tilt, and Rotation Options For Use with X15 Pipo
