New Interface Multi-Axis Sensor Selection Guide

Interface multi-axis sensors have multiple benefits for test and measurement applications. Beyond providing more data, they consolidate measurement signals and conserve test space.

Interface multi-axis sensors are like other force and torque sensors with strain gage bridges bonded to machined flexures. Each bridge typically defines a measurement axis. Interface offers multiple configurations for 2, 3, or 6-axis options: axial and torque, axial and shear, axial and moment, and all six degrees.

Most force and torque sensors are bidirectional, tension, and compression. Many sensors can be dual or triple-bridge for dedicated or redundant signals. These types of load cells output the same signal and direction of measurement.

Uniquely, multi-axis sensors have additional bridges to provide output signals for varying axes or types of mechanical loading. Interface multi-axis sensors are designed to provide a complete picture of the test article by quantifying reaction loads through the test article on the “non-measure” side.

These specialized load cells are used in various applications across industries, including aerospace, robotics, automotive, and medical device research. These sensors are specifically designed for applications requiring measuring moment and axial loads to determine the center of gravity or misalignment. They are used for tests requiring simultaneous force and torque monitoring, such as bearing test and material test machines, rheometry test machines for rubber testing, or continuous stress testing of equipment like pumps and master key systems. The multi-axis sensor offers better fatigue testing through setup and load verification.

Below is a demonstration using Interface’s 6-Axis Sensor with our BX8 to measure the precise movements of a robotic hand.

6-Axis BX8 Robot Hand

Watch this video on YouTube

For additional information on this type of application, check out Manufacturing: 6-Axis Force Plate Robotic Arm and Using Multi-Axis Sensors to Bring Robotics to Life.

Selecting a Multi-Axis Sensor

To find the suitable multi-axis sensor for your unique requirements, Interface’s latest resource guide is a versatile reference to compare the sensor types, features, capabilities, and options. The Interface Multi-Axis Sensor Selection Guide lets you quickly evaluate the various sensor types based on whether you need a 2-axis, 3-axis, or 6-axis. Reviewing the products based on features and capabilities is easy, including tension and compression, axial torsion, force and torque, side and radial force, compact, temperature compensated, moment compensated, flange mount, or a center through hole.

This new resourceful tool also helps in reviewing various options, including connector protection, connector options, standardized output, TEDS, CANbus, internal shunt cal, custom calibration, multiple bridges, special threads, dual-diaphragm, special temperature range, cable length, and more.

How the Multi-Axis Selection Guide Works

GO TO: Interface Multi-Axis Sensor Selection Guide

STEP ONE: Select the Number Of Axis You Want to Measure

STEP TWO: Identify Multi-Axis Sensor Features And Capabilities

Axial Torsion
Center Through Hole
Compact
Flange Mount
Force and Torque
High Capacity
Moment Compensated
Side and Radial Force
Temperature Compensated
Tension and Compression

STEP THREE: Choose the Multi-Axis Sensor Options

Active output ±10V
Active output ±5V
Add a connector to a cable
Cable length
CANbus
Connector options
Connector protection
Custom calibration
Dual diaphragm
Integrated speed and angle measurements option
Internal Shunt Cal
Mating cable assembly
Multiple bridges
Special temperature range
Special threads
Special versions on request
Speed up to 3000 rpm
Standardized output
TEDS

Interface a range of resources related to our multi-axis sensors. Here is a recent webinar that helps give you a background on these sensors and applications and technical tips.

Inventive Multi Axis And Instrumentation Webinar
